| 排渣閘閥 |
| 發表時間：2011-5-26 文字 〖 大 中 小 〗 閱讀次數：7207 [關閉窗口] |
|
 |
|
公稱壓力PN |
公稱通經DN |
主要外形尺寸和連接尺寸 |
WT(kg) |
| L |
D |
D1 |
D2 |
D6 |
B |
F |
N-ØD |
H |
DO |
| 1.6MPa |
50 |
250 |
160 |
125 |
100 |
- |
16 |
3 |
4-18 |
335 |
250 |
60 |
| 80 |
280 |
195 |
160 |
135 |
- |
20 |
3 |
8-18 |
510 |
280 |
78 |
| 100 |
300 |
215 |
180 |
155 |
- |
20 |
3 |
8-18 |
685 |
300 |
96 |
| 150 |
350 |
280 |
240 |
210 |
- |
24 |
3 |
8-23 |
790 |
300 |
158 |
| 200 |
400 |
335 |
295 |
265 |
- |
26 |
3 |
12-23 |
885 |
350 |
222 |
| 250 |
450 |
405 |
355 |
320 |
- |
30 |
3 |
12-25 |
1015 |
400 |
289 |
| 300 |
500 |
460 |
410 |
375 |
- |
30 |
3 |
12-25 |
1190 |
450 |
365 |
| 350 |
550 |
520 |
470 |
435 |
- |
34 |
4 |
16-25 |
1350 |
500 |
558 |
| 400 |
600 |
580 |
525 |
485 |
- |
36 |
4 |
16-25 |
1460 |
500 |
850 |
| 450 |
650 |
640 |
585 |
545 |
- |
40 |
4 |
20-30 |
1620 |
550 |
1164 |
| 500 |
700 |
705 |
650 |
608 |
- |
44 |
4 |
20-34 |
1800 |
550 |
1482 |
| 2.5MPa |
50 |
250 |
160 |
125 |
100 |
- |
20 |
3 |
4-18 |
335 |
250 |
99 |
| 80 |
280 |
195 |
160 |
135 |
- |
22 |
3 |
8-18 |
510 |
280 |
118 |
| 100 |
300 |
230 |
190 |
160 |
- |
24 |
3 |
8-23 |
685 |
300 |
147 |
| 150 |
350 |
300 |
250 |
218 |
- |
30 |
3 |
8-25 |
790 |
300 |
204 |
| 200 |
400 |
360 |
310 |
278 |
- |
34 |
3 |
12-25 |
885 |
350 |
273 |
| 250 |
450 |
425 |
370 |
332 |
- |
36 |
3 |
12-30 |
1015 |
400 |
373 |
| 300 |
500 |
485 |
430 |
390 |
- |
40 |
4 |
16-30 |
1190 |
450 |
478 |
| 350 |
550 |
550 |
490 |
448 |
- |
44 |
4 |
16-34 |
1350 |
500 |
680 |
| 400 |
600 |
610 |
550 |
505 |
- |
48 |
4 |
16-34 |
1460 |
500 |
1008 |
| 450 |
650 |
660 |
600 |
555 |
- |
50 |
4 |
20-34 |
1620 |
550 |
1344 |
| 500 |
700 |
730 |
660 |
610 |
- |
52 |
4 |
20-41 |
1800 |
550 |
1827 |
| 4.0MPa |
50 |
250 |
160 |
125 |
100 |
88 |
20 |
3 |
4-18 |
340 |
250 |
98 |
| 80 |
310 |
195 |
160 |
135 |
121 |
22 |
3 |
8-18 |
508 |
300 |
126 |
| 100 |
350 |
230 |
190 |
160 |
150 |
24 |
3 |
8-23 |
680 |
300 |
156 |
| 150 |
450 |
300 |
250 |
218 |
204 |
30 |
3 |
8-25 |
800 |
400 |
228 |
| 200 |
550 |
375 |
320 |
282 |
260 |
38 |
3 |
12-30 |
875 |
500 |
298 |
| 250 |
650 |
445 |
385 |
345 |
313 |
42 |
3 |
12-34 |
1010 |
500 |
372 |
| 300 |
750 |
510 |
450 |
408 |
364 |
46 |
4 |
16-34 |
1180 |
550 |
450 |
| 350 |
850 |
570 |
510 |
465 |
422 |
52 |
4 |
16-34 |
1145 |
600 |
530 |
| 400 |
950 |
655 |
585 |
535 |
474 |
58 |
4 |
16-41 |
1280 |
600 |
610 |
| 450 |
1050 |
680 |
610 |
560 |
524 |
60 |
4 |
20-41 |
1415 |
700 |
690 |
| 500 |
1150 |
755 |
670 |
612 |
576 |
62 |
4 |
20-48 |
1560 |
750 |
772 |
| 6.46MPa |
50 |
250 |
175 |
135 |
105 |
- |
26 |
3 |
4-23 |
340 |
250 |
142 |
| 80 |
310 |
210 |
170 |
140 |
- |
30 |
3 |
8-23 |
508 |
300 |
168 |
| 100 |
350 |
250 |
200 |
168 |
- |
32 |
3 |
8-25 |
680 |
300 |
210 |
| 150 |
450 |
340 |
280 |
240 |
- |
38 |
3 |
8-34 |
800 |
400 |
270 |
| 200 |
550 |
405 |
345 |
300 |
- |
44 |
3 |
12-34 |
875 |
500 |
367 |
| 250 |
650 |
470 |
400 |
352 |
- |
48 |
3 |
12-41 |
1010 |
500 |
450 |
| 300 |
750 |
530 |
460 |
415 |
- |
54 |
4 |
16-41 |
1180 |
550 |
532 |
| 350 |
850 |
595 |
525 |
475 |
- |
60 |
4 |
16-41 |
1145 |
600 |
548 |
| 400 |
950 |
670 |
585 |
525 |
- |
66 |
4 |
16-48 |
1280 |
600 |
615 |
| 450 |
1050 |
715 |
630 |
570 |
- |
70 |
4 |
20-48 |
1415 |
700 |
695 |
| 500 |
1150 |
800 |
705 |
610 |
- |
76 |
4 |
20-54 |
1560 |
750 |
778 | 文章分頁：1
|
|
|
|
|
