| API球閥 |
| 發表時間：2011-5-26 文字 〖 大 中 小 〗 閱讀次數：6121 [關閉窗口] |
|
 |
|
產品規范 |
設計規范 |
結構長度 |
連接法蘭 |
試驗與檢驗 |
產品標識 |
供貨規范 |
API608
API6D |
ANSIB16.10
API6D |
ANSIB16.5 |
API598
API6D |
MSSSP-25
API6D |
API608
API6D |
|
公稱壓力PN |
150Lb |
300Lb |
400Lb |
600Lb |
| 殼體試驗壓力 |
3.1 |
7.5 |
10.2 |
15.0 |
| 密封試驗（液） |
2.2 |
5.5 |
7.48 |
11.0 |
| 密封試驗（氣） |
0.5-0.7 |
| 適用介質 |
C P R
水、油品、蒸汽 硝酸類 醋酸類 |
| 適用溫度 |
≤200°C |
|
名稱 |
WCB類 |
CF8類 |
CF3類 |
CF8M類 |
CF3M類 |
| 閥體左體 |
A216-WCB |
A315-CF8 |
A35-CF3 |
A315-CF8M |
A315-CF3M |
| 球體 |
B2-B8 |
A105-1025 |
A182-F304L |
A182-F304L |
A132-F316 |
A182-F316L |
| B8以上 |
A216-WCB |
A351-CF8M |
A351-CF3 |
A351-CF8M |
A351-CF3M |
| 閥桿 |
A182-F6A |
A182-F304 |
A182-F304L |
A182-F336 |
A182-F316L |
| 閥座 |
PTFE/增強FTFE/NYLIN PTFE/Reinforeed PTFE/Nyion |
| 閥座支撐圈 |
A105-1025 |
A182-F304 |
A182-F304L |
A182-F316 |
A182-F316L |
| 彈簧 |
3yc-7/17-49II |
| O形圈 |
NBR |
氟橡膠 Viton |
| 螺柱 |
A193-B7 |
A193-B8 |
| 螺母 |
A194-2H |
A194-8 |
|
DN |
主要外形尺寸和連接尺寸 |
WT(kg) |
備注 |
| D |
L-RF |
L-BW |
D |
D1 |
D2 |
B |
F |
N-Ø |
H1 |
H2 |
DO |
| CLASS 150 AIB(3)41, (3)47, (3)61, (3)67F(N,PPL),{P,R,V} |
| 1/2m |
13 |
108 |
- |
89 |
60.5 |
35 |
11.2 |
1.6 |
4-16 |
- |
59 |
130 |
2.3 |
浮動球 |
| 3/4m |
19 |
117 |
- |
98 |
70 |
43 |
11.2 |
1.6 |
4-16 |
- |
63 |
130 |
3.0 |
| 1m |
25 |
127 |
- |
108 |
79.5 |
51 |
11.2 |
1.6 |
4-16 |
- |
75 |
160 |
4.5 |
| 1 1/2m |
38 |
165 |
190 |
127 |
98.5 |
73 |
14.3 |
1.6 |
4-16 |
- |
95 |
230 |
7.0 |
| 2 |
51 |
178 |
216 |
152 |
120.5 |
92 |
15.9 |
1.6 |
4-19 |
- |
107 |
230 |
9.5 |
固定球
浮動球 |
| 2 1/2m |
61 |
190 |
241 |
178 |
139.5 |
105 |
17.5 |
1.6 |
4-19 |
- |
142 |
400 |
15.0 |
| 3m |
76 |
203 |
283 |
190 |
152.5 |
127 |
19.1 |
1.6 |
4-19 |
- |
152 |
400 |
19.0 |
| 4m |
102 |
229 |
305 |
229 |
190.5 |
157 |
23.9 |
1.6 |
8-19 |
- |
178 |
700 |
33.0 |
| 5m |
127 |
356 |
- |
254 |
216 |
186 |
23.9 |
1.6 |
8-22 |
- |
252 |
1100 |
58.0 |
| 6m |
52 |
394 |
457 |
279 |
241.5 |
216 |
54.5 |
1.6 |
8-22 |
- |
272 |
1100 |
93.0 |
| 8m |
203 |
457 |
521 |
343 |
298.5 |
270 |
58.6 |
1.6 |
8-22 |
- |
342 |
1500 |
160.0 |
| 8m |
203 |
457 |
521 |
343 |
298.5 |
270 |
28.6 |
1.6 |
8-22 |
- |
398 |
600 |
180.0 |
固定球 |
| 10m |
254 |
533 |
559 |
406 |
362 |
324 |
30.2 |
1.6 |
12-25 |
335 |
495 |
600 |
240.0 |
| 12m |
305 |
610 |
635 |
482.6 |
431.8 |
381 |
31.8 |
1.6 |
12-25 |
385 |
580 |
800 |
390.0 |
| 14m |
337 |
686 |
762 |
535 |
476 |
412.8 |
35 |
1.6 |
12-29 |
430 |
625 |
800 |
510.0 |
| 16m |
387 |
162 |
838 |
597 |
539.5 |
469.9 |
36.6 |
1.6 |
162-29 |
470 |
720 |
800 |
750.0 |
| 20m |
489 |
914 |
991 |
698 |
635 |
58.2 |
42.9 |
1.6 |
20-32 |
590 |
840 |
800 |
1190 |
| 24m |
591 |
1067 |
1143 |
813 |
749.5 |
692.2 |
47.8 |
1.6 |
20-35 |
700 |
1050 |
800 |
2100 |
| 26m |
686 |
1245 |
1346 |
927.1 |
836.6 |
800.1 |
71.4 |
1.6 |
28-35 |
780 |
1150 |
800 |
3000 |
|
DN |
主要外形尺寸和連接尺寸 |
WT(kg) |
備注 |
| D |
L-RF |
L-BW |
D |
D1 |
D2 |
B |
F |
N-Ø |
H1 |
H2 |
DO |
| CLASS 300 AIB(3)41, (3)47, (3)67F(N,PPL),{P,R,V} |
| 1/2m |
13 |
140 |
- |
95 |
66.5 |
35 |
14.2 |
1.6 |
4-16 |
- |
59 |
130 |
2.5 |
浮動球 |
| 3/4m |
19 |
152 |
- |
117 |
82.5 |
43 |
15.9 |
1.6 |
4-19 |
- |
63 |
130 |
3.5 |
| 1m |
25 |
165 |
- |
124 |
89 |
51 |
17.5 |
1.6 |
4-19 |
- |
75 |
160 |
5.5 |
| 1 1/2m |
38 |
190 |
190 |
156 |
114.5 |
73 |
20.7 |
1.6 |
4-22 |
- |
95 |
230 |
10.5 |
| 2 |
51 |
216 |
216 |
165 |
127 |
92 |
22.3 |
1.6 |
8-19 |
- |
107 |
230 |
14.5 |
固定球
浮動球 |
| 2 1/2m |
61 |
241 |
241 |
190 |
149 |
105 |
25.4 |
1.6 |
8-22 |
- |
142 |
400 |
23.5 |
| 3m |
76 |
283 |
283 |
210 |
168 |
127 |
28.6 |
1.6 |
8-22 |
- |
152 |
400 |
30.0 |
| 4m |
102 |
305 |
305 |
254 |
200 |
157 |
31.8 |
1.6 |
8-22 |
- |
178 |
700 |
55.0 |
| 5m |
127 |
381 |
- |
279 |
235 |
186 |
35 |
1.6 |
8-22 |
- |
252 |
1100 |
81.0 |
| 6m |
52 |
403 |
457 |
318 |
270 |
216 |
36.5 |
1.6 |
12-22 |
- |
272 |
1100 |
118.0 |
| 8m |
203 |
502 |
521 |
381 |
330 |
270 |
41.3 |
1.6 |
12-25 |
- |
342 |
1500 |
200.0 |
| 8m |
203 |
502 |
521 |
381 |
330 |
270 |
41.3 |
1.6 |
12-25 |
- |
398 |
600 |
220.2 |
固定球 |
| 10m |
254 |
568 |
559 |
444 |
387.5 |
324 |
17.7 |
1.6 |
16-29 |
335 |
495 |
600 |
365 |
| 12m |
305 |
648 |
635 |
520.8 |
451 |
381 |
50.8 |
1.6 |
16-32 |
385 |
580 |
800 |
530 |
| 14m |
337 |
762 |
762 |
584.2 |
514.5 |
412.8 |
53.8 |
1.6 |
20-32 |
430 |
625 |
800 |
740 |
| 16m |
387 |
838 |
838 |
647.8 |
571.5 |
469.9 |
57.2 |
1.6 |
20-35 |
470 |
720 |
800 |
1030 |
| 20m |
489 |
891 |
991 |
774.8 |
685.8 |
584.2 |
63.5 |
1.6 |
24-35 |
590 |
840 |
800 |
1540 |
| 24m |
591 |
1143 |
1143 |
914.4 |
812.8 |
692.2 |
69.8 |
1.6 |
24-41 |
700 |
1050 |
800 |
2600 |
| 28m |
686 |
1346 |
1346 |
1035 |
939.8 |
800.1 |
85.9 |
1.6 |
28-44.5 |
780 |
1150 |
800 |
3900 |
|
DN |
主要外形尺寸和連接尺寸 |
WT(kg) |
備注 |
| D |
L-RF |
L-BW |
D |
D1 |
D2 |
B |
F |
N-Ø |
H1 |
H2 |
DO |
| CLASS 600 AIB(3)41, (3)47, (3)67F(N,PPL),{P,R,V} |
| 1/2m |
13 |
165 |
165 |
95 |
66.5 |
35 |
14.3 |
6.4 |
4-16 |
- |
59 |
130 |
6.5 |
浮動球 |
| 3/4m |
19 |
190 |
190 |
117 |
82.5 |
43 |
15.9 |
6.4 |
4-19 |
- |
63 |
160 |
9 |
| 1m |
25 |
216 |
216 |
124 |
89 |
51 |
17.5 |
6.4 |
4-19 |
- |
75 |
160 |
13 |
| 1 1/2m |
38 |
241 |
241 |
156 |
114.5 |
73 |
22.3 |
6.4 |
4-22 |
- |
95 |
230 |
16.5 |
| 2m |
51 |
292 |
292 |
165 |
127 |
92 |
25.4 |
6.4 |
8-19 |
- |
107 |
700 |
25 |
固定球
浮動球 |
| 4m |
61 |
406 |
406 |
254 |
200 |
157.2 |
35 |
6.4 |
8-25 |
- |
178 |
700 |
66 |
| 6m |
76 |
495 |
495 |
317.5 |
270 |
216 |
41 |
6.4 |
12-25 |
250 |
300 |
600 |
145 |
| 8m |
102 |
597 |
597 |
381 |
330 |
269.8 |
47.8 |
6.4 |
12-28.5 |
294 |
374 |
800 |
250 |
固定球 |
| 10m |
127 |
673 |
673 |
445 |
387.5 |
324 |
53.8 |
6.4 |
16-32 |
370 |
445 |
800 |
540 |
| 12m |
52 |
762 |
762 |
521 |
451 |
381 |
57 |
6.4 |
16-35 |
420 |
515 |
800 |
780 |
| 14m |
203 |
826 |
826 |
584 |
514.5 |
413 |
60.5 |
6.4 |
20-35 |
460 |
550 |
800 |
1000 |
| 16m |
203 |
902 |
902 |
648 |
571.5 |
470 |
63.5 |
6.4 |
20-38 |
505 |
615 |
800 |
1300 |
| 20m |
254 |
1054 |
1054 |
775 |
686 |
584.2 |
69.8 |
6.4 |
20-41 |
630 |
810 |
|
2100 |
| 24m |
305 |
1232 |
1232 |
915 |
812.8 |
692.2 |
76 |
6.4 |
24-48 |
685 |
845 |
800 |
3400 |
| 28m |
337 |
1397 |
1397 |
1035 |
939.8 |
800 |
95.3 |
6.4 |
28-51 |
860 |
1087 |
800 |
5000 |
|
DN |
主要外形尺寸和連接尺寸 |
WT(kg) |
備注 |
| D |
L-RF |
L-BW |
D |
D1 |
D2 |
B |
F |
N-Ø |
H1 |
H2 |
DO |
| CLASS 600 A6B(3)41, (3)47, (3)67F(N,PPL),{P,R,V} |
| 1/2m |
13 |
165 |
165 |
95 |
56.5 |
35 |
14.3 |
6.4 |
4-16 |
- |
59 |
160 |
7.5 |
浮動球 |
| 3/4m |
19 |
190 |
190 |
117 |
82.5 |
43 |
15.9 |
6.4 |
4-19 |
- |
63 |
160 |
10.5 |
| 1m |
25 |
216 |
216 |
124 |
89 |
51 |
17.5 |
6.4 |
4-19 |
- |
75 |
230 |
14.5 |
| 1 1/2m |
38 |
241 |
241 |
156 |
114.5 |
73 |
22.3 |
6.4 |
4-22 |
- |
95 |
400 |
18.5 |
| 2m |
51 |
292 |
292 |
165 |
127 |
92 |
25.4 |
6.4 |
8-19 |
- |
107 |
700 |
25 |
固定球
浮動球 |
| 4m |
102 |
432 |
432 |
273 |
216 |
157.2 |
38 |
6.4 |
8-25 |
- |
178 |
1100 |
76 |
| 6m |
152 |
550 |
550 |
355.6 |
282.1 |
216 |
47.2 |
6.4 |
12-29 |
250 |
300 |
600 |
127 |
| 8m |
203 |
660 |
660 |
419.5 |
349.2 |
269.8 |
55.7 |
6.4 |
12-32 |
294 |
374 |
800 |
350 |
固定球 |
| 10m |
254 |
787 |
787 |
508 |
431.8 |
324 |
63.5 |
6.4 |
16-35 |
370 |
445 |
800 |
660 |
| 12m |
305 |
838 |
838 |
559 |
489 |
381 |
66.5 |
6.4 |
20-35 |
420 |
515 |
800 |
820 |
| 14m |
337 |
889 |
889 |
603.2 |
527 |
413 |
69.8 |
6.4 |
20-38 |
460 |
550 |
800 |
1130 |
| 16m |
387 |
991 |
991 |
686 |
603.2 |
470 |
76.2 |
6.4 |
20-41 |
505 |
615 |
800 |
1550 |
| 20m |
489 |
1194 |
1194 |
818 |
724 |
584.2 |
89 |
6.4 |
24-44.5 |
630 |
810 |
|
2800 |
| 24m |
591 |
1397 |
1397 |
940 |
838.2 |
692.2 |
101.6 |
6.4 |
24-51 |
825 |
1010 |
800 |
5300 |
| 28m |
686 |
1549 |
1549 |
1073 |
965.2 |
800 |
111.3 |
6.4 |
28-55 |
970 |
1180 |
800 |
6500 | 文章分頁：1
|
|
|
|
|
